| Name | Biological Microscope BM-Z102 BM-F104 BM-Z106 BM-Z110 BM-Z112 |
| Code | biobase-0947 |
| Type | Standard |
| Brand | Biobase |
| Category | Optical Instruments |
| subcategory | Microscope |
| Unit | pcs (pcs) |
| test In Stock | Yes |
| Berminat hub kami: |  |
Technical Parameters:
Model | BM-Z102 | BM-F104 | BM-Z106 | BM-Z110 | BM-Z112 | |
Eyepiece | Wide field eyepiece: WF10X, (WF16X optional) | √ | √ | √ | √ | √ |
Viewing Head | Compensation free binocular head inclined at 30° | / | √ | / | / | / |
Sliding binocular head, inclined at 45° | / | / | √ | / | / | |
Sliding trinocular head, inclined at 45° | / | / | / | / | √ | |
Monocular with video teaching head | √ | / | / | / | / | |
Achromatic Objective | 4X, 10X, 40X(Spring), 100X(Spring, Oil) | √ | √ | √ | √ | √ |
Nosepiece | Quadruple nosepiece | √ | √ | √ | √ | √ |
Stage | Double layer mechanical stage size 132*140mm, moving range 75*45mm | √ | √ | √ | √ | √ |
Base Accessories | Black decorative panel | ● | ● | ● | ● | √ |
Focusing | Coaxial coarse and fine adjustment, focusing range 30mm, focusing Interval 0.002mm | √ | √ | √ | √ | √ |
Condenser | Abbe NA=1.25 with iris diaphragm&filter | √ | √ | √ | √ | √ |
Illumination | LED light source(halogen lamp optional) | √ | √ | √ | √ | √ |
Power Supply | AC Input 100~230V, DC Output 12V | √ | √ | √ | √ | √ |
Package Size(W*D*H)mm | 320*280*420mm | |||||
Gross Weight(kg) | 5.2 | 5.6 | 5.6 | 6 | 6 | |
Note: √ Standard Outfit, ● Optional
